DAXTROMN GGH-3.5KW Solar Inverter 5000W Pure Sine Wave 100A MPPT Solar Charger Max. 500VDC PV Input

Availability:

330 in stock


384,43

330 in stock

  • Brand: DAXTROMN
  • Model: GGH-3.5KW
  • Type: Solar Inverter
  • Phase: 1-Phase
  • Maximum PV Input Power: 3500W
  • Rated Output Power: 3500W/3500VA
  • MPPT Voltage Range: 120-450VDC
  • Surge power: 7000VA

Highlights

Pure Sine Wave Inverter

The HYBRID Solar Inverter provides clean, stable power with a pure sine wave output, ensuring compatibility with sensitive home appliances and personal computers. This feature guarantees optimal performance and longevity of your devices.

Built-in MPPT Solar Controller

Equipped with a built-in Maximum Power Point Tracking (MPPT) solar controller, this Solar Inverter maximizes the efficiency of your solar panels. It ensures that the maximum amount of energy is harvested from your solar system, even under varying weather conditions.

Auto Restart Function

In the event of a power outage, the inverter will automatically restart once the AC power is restored. This feature ensures that your devices and systems resume operation without manual intervention.

Comprehensive Protection

The HYBRID Solar Inverter includes overload, over temperature, and short circuit protection. These safety features safeguard your equipment and ensure reliable operation under various conditions.

Smart Battery Charger Design

The inverter features a smart battery charger design that optimizes battery performance. This ensures efficient charging and discharging cycles, maximizing the lifespan and reliability of your batteries.

Cold Start Function

The HYBRID INVERTER includes a cold start function, allowing it to start and operate even in low-temperature environments. This feature ensures that you have access to power when you need it most, regardless of the weather conditions.

Specification

General

Brand: DAXTROMN
Type: Solar Inverter
Model: GGH-3.5KW
Color: Blue-White

Specification

Phase: 1-Phase
Maximum PV Input Power: 3500W
Rated Output Power: 3500W/3500VA
Maximum Solar Charging Current: 100A

GRID-TIE OPERATION
Nominal DC Voltage/Maximum DC Voltage: 360VDC/500VDC
Start-up Voltage/Initial Feeding Voltage: 90VDC/120VDC
MPPT Voltage Range: 120-450VDC
Number of MPPT/Max Input Current: 1/23A

GRID OUTPUT(AC)
Nominal Output Voltage: 220/230/240VAC
Output Voltage Range: 195.5-253VAC
Nominal Output Current: 15.7A
Power Factor: >0.99

OFF-GRID OPERATION
AC Input:
AC Start-up Voltage/Auto Restart Voltage: 120-140VAC/180VAC
Acceptable Input Voltage Range: 90-280VAC or 170-280VAC
Maximum AC Input Current: 60A
Nominal operating frequency: 50/60Hz
Surge power: 7000VA

BATTERY MODE OUTPUT(AC)
Nominal Output Voltage: 220/230/240VAC
Output Waveform: Pure sine wave
Efficiency(DC to AC): 94%

BATTERY&CHARGER
Nominal DC Voltage:
Maximum Solar Charging Current: 100A
Maximum AC Charging Current: 60A

Operating Temperature:  -10-50°C

Weight & Size

Product Weight: 10kg
Package Weight: 11kg
Product Size(L x W x H): 49x30x11cm
Package Size(L x W x H): 54x35x18cm

Package Contents

1 x Solar Inverter
1 x User Manual
